Further details for you
This wheel can be attached either hub centered (MZ) or bolt centered (BZ). For BZ, ball collar nuts or taper collar nuts are used. For MZ, two additional special bushings (mounted on opposite wheel studs) are required to ensure good mounting. Ask your winkler technical specialist.
Brand
Maxion Color
silver External valve suitable for disk brakes
yes Half dual spacing (mm)
125 Including valve
nein Info 1
Mercedes Load-bearing capacity (kg)
1700 Material
steel Method of centering
bolt and hub centering Number of mounting bores
6 Rim offset (mm)
115 Rim size
17.5x6 Version valve
cranked Version wheel bolt holes
B 103 Weight (kg)
22 ø center hole (mm)
202 ø hole circle (mm)
245 ø valve hole (mm)
9,7 ø wheel stud bore (mm)
21
