Brand
Parker Construction form
straight For ø pipe A (mm)
20 For ø pipe B (mm)
18 Internal thread A metric
M 30x2 Internal thread B metric
M 26x1,5 Length L (mm)
47 Material
steel Operating pressure (bar)
400 Production series
heavylight
Sealing
24° sealing cone with O-ring Standard DIN
3865 Standard ISO
8434-1 Surface
Cr6-free galvanized Tube AD series
20 S/18 L Type
GZR Weight (kg)
0,224 Width across flats nut CH1 (mm)
32 Width across flats nut CH2 (mm)
36
