Brand
other Construction form
straight For ø pipe A (mm)
10 For ø pipe B (mm)
8 Info 1
DKO Internal thread A metric
M 16x1,5 Internal thread B metric
M 14x1,5 Length L (mm)
36,8 Material
steel Operating pressure (bar)
315 Production series
light Sealing
24° sealing cone with O-ring Standard DIN
3865 Standard ISO
8434-1 Surface
Cr6-free galvanized Tube AD series
10 L/8 L Type
GZR Weight (kg)
0,05 Width across flats nut CH1 (mm)
19 Width across flats nut CH2 (mm)
17
