The inscriptions specified relate to the diaphragm. Various complete air springs are possible. Please verify the required version.
Air connection
1 separate Attachment type at bottom
4 stud bolt Attachment type at top
4 stud bolt Brand
winkler Distance mount bottom (mm)
232 Distance mount top (mm)
232 Inscription Airkraft
2B-350 Inscription Blacktech
2C-3032C-303-270P01
Inscription Firestone
12x2 Inscription Goodyear
578-92-3-2450 Inscription springride/Dunlop France
12x212X2 A50
Measures air connection
M 16x1,5 Measures mounting bottom
4x M 10 Measures mounting top
4x M 10 Type of construction
bellows Version
complete Weight (kg)
7,096
