The inscriptions specified relate to the diaphragm. Various complete air springs are possible. Please verify the required version.
Air connection
1 separate Attachment type at bottom
4 holes Attachment type at top
2 stud bolt Brand
winkler Distance mount top (mm)
150 Height rolling piston (mm)
141 Hole circle bottom (mm)
200 Inscription Airtech
3261834022
34022-03
Inscription Blacktech
7513375133 CP3
Inscription CF Gomma
1T 300-37 Inscription ContiTech
4022 N4022 N P03
Inscription Firestone
1T15M Series1T17B Series
C01 M58 0573
C01 M58 1300
Inscription Gart
D278/S Inscription Goodyear
566-22-3-503566-22-3-526
Inscription Phoenix
1DK22E1DK22E-9
Inscription Prime-Ride
1R11-710 Inscription SAF
2618V Inscription springride/Dunlop France
D12A05 Inscription Vibracoustic
V1DK22EV1DK22E-9
Inscription Wabco
896 130 147 4951 811 710 0
Material rolling piston
plastic Measures air connection
M 22x1,5 Measures mounting bottom
4x ø 7.8 mm Measures mounting top
2x M 12 Type of construction
rolling bellows Version
complete Weight (kg)
7,24 ø rolling piston (mm)
240
