scraper ring for axially moving rods on hydraulic working cylinders, tappets and rod guides
The wiper rings have the task of preventing the penetration of dust, dirt, sand grains and metal chips. This is achieved through their special shaping. This largely prevents scoring and protects the guide parts.
Brand
other For width notch (mm)
4 Material
NBR Temperature range from (°C)
-35 Temperature range to (°C)
100 Version
without metal jacket Weight (kg)
0,01 Width overall (mm)
7 ø external (mm)
73 ø internal (mm)
65
