Assembly flange drive
4-hole 72x100 mm M 8 Brand
Bosch-Rexroth Center ø flange (mm)
80 Delivery volume (cm³/r)
16 Direction of rotation
left Manufactured size
F Max. pressure (bar)
280 Max. revolution (rpm)
3000 Mounting pressure connection
hole circle 35 mm M 6 Mounting suction connection
hole circle 40 mm M 6 Operating pressure (bar)
250 Optional equipment valve
without valve Specification drive
splined shaft DIN 5482 B17x14 Usage
fan drive system Version
single pump Weight (kg)
3,734 ø pressure connection (mm)
15 ø shaft/hub (mm)
16,5 ø suction connection (mm)
20
