scope of delivery: engine including pressure limiting valve 24 VDC
Assembly flange drive
4-hole 100x72 mm M 8 Brand
Bosch-Rexroth Center ø flange (mm)
80 Direction of rotation
right Displacement (cm³/r)
22,5 Info 1
24 V Manufactured size
F Material housing
aluminum Max. pressure (bar)
210 Max. revolution (rpm)
3000 Mounting oil connection A
hole circle 35 mm M 6 Mounting oil connection B
hole circle 40 mm M 6 Operating pressure (bar)
180 Specification drive
shaft conical 1:5 Usage
fan drive Weight (kg)
6,153 ø oil connection A (mm)
15 ø oil connection B (mm)
20
