Assembly flange drive
SAE B-flange Brand
Bosch-Rexroth Center ø flange (mm)
101.6 Delivery volume (cm³/r)
22,5 Direction of rotation
right Manufactured size
S Material housing
aluminum Max. pressure (bar)
300 Max. revolution (rpm)
3500 Mounting pressure connection
hole circle 35 mm M 6 Mounting suction connection
hole circle 55 mm M 8 Operating pressure (bar)
250 Optional equipment valve
without valve Specification drive
shaft ANSI B 92.1 9 teeth Usage
steering Version
single pump Weight (kg)
5,15 ø pressure connection (mm)
15 ø shaft/hub (mm)
15,5 ø suction connection (mm)
26
