Further details for you
delivery with securing nut
Brand
winkler Comparable with
Argus RKContitech 60
Contitech 61
Vosswinkel RS
Connection type
tube connection Coupling type
flat sealing For ø pipe B (mm)
12 Manufactured size
AG 2 Material
steel Nominal diameter (mm)
8 Operating pressure (bar)
400 Production series
heavy Sealing
24° inner cone Surface
Cr6-free galvanized Thread external B metric
M 20x1,5 Thread external C metric
M 30x1 Thread external coupling metric
Rd 32x3 Tube AD series
12 S Type/series
RK Version
fixed Weight (kg)
0,23 Width across flats body (mm)
36 Width across flats securing nut (mm)
36
