Angle (°)
90 Armatures series
46 Axle D (mm)
32 Brand
Parker Form connection
90° union nut Length A (mm)
39 Length B (mm)
63 Material
steel Nominal diameter hose (inches)
1/2 Nominal diameter hose (mm)
12 Operating pressure (bar)
350 Sealing
sealing cone 37° Size
08 Surface
Cr6-free galvanized Thread internal T
JIC 7/8-14 Type
DKJ Usage hose type Parker
441461LT
462
462ST
463
492
492ST
692
692TWIN
Weight (kg)
0,146 Width across flats nut CH (mm)
27
