With the new Quick-Fit versions, the upper and lower parts are now connected with four stud bolts instead of six screws. This makes it more convenient and quicker to replace wear parts during maintenance work.
Brand
Haldex Connection 1 – power input
M 22x1,5 Connection 2 – power output
M 22x1,5 Connection 3 – atmosphere
venting Deposit item
no Electrical connection
Kostal M 27x1 Info 1
for Quick-Fit version 4 stud bolts Info 2
without hose connection Max. operating pressure (bar)
20 Ref. no.
Haldex 92693S Reman
no Type
Consep Usage
oil and water Weight (kg)
2,05
