Assembly flange drive
4-hole 161.6x161.6 mm Brand
Parker Displacement (cm³/r)
150 Leakage oil connection
M 22x1.5 internal thread Material housing
cast steel Max. oil flow (l/min)
547 Max. pressure (bar)
480 Max. revolution (rpm)
3700 Max. torque (Nm)
241 Oil connection A
1 1/2 inch SAE 6000 Oil connection B
1 1/2 inch SAE 6000 Operating pressure (bar)
420 Specification drive
splined shaft W50x2x24x9g Type
F12-152 Weight (kg)
46,3 ø shaft/hub (mm)
40
