Further details for you
delivery with securing nut
Brand
winkler Comparable with
Argus RKContitech 60
Contitech 61
Vosswinkel RS
Connection type
tube connection Coupling type
flat sealing For ø pipe B (mm)
22 Manufactured size
AG 6 Material
steel Nominal diameter (inches)
3/4 Nominal diameter (mm)
20 Operating pressure (bar)
320 Production series
light Sealing
24° inner cone Surface
Cr6-free galvanized Thread external B metric
M 30x2 Thread external C metric
M 45x1,5 Thread external coupling metric
Rd 48x3 Tube AD series
22 L Type/series
RK Version
fixed Weight (kg)
0,652 Width across flats body (mm)
55 Width across flats securing nut (mm)
55
