Further details for you
Attachment type on bottom side
eye Attachment type rod side
without Brand
Haco Installation dimension (mm)
693 Oil connection bottom side
1/4 inch internal thread Oil connection rod side
M 16x1,5 Operating pressure (bar)
185 Piston ø (mm)
75 Stroke (mm)
280 Weight (kg)
16,64 ø casing tube (mm)
85 ø mounting bottom side (mm)
41 ø mounting rod side (mm)
35 ø piston rod (mm)
50
