multipurpose hose for the passage and suction of acids, alkalis, ketones, aldehydes, esters, aromatic, aliphatic and chlorinated hydrocarbons high flexibility and easier use due to corrugated surface
Bending radius (mm)
230 Braiding
without Brand
winkler Burst pressure (bar)
48 Color exterior
black Color interior
black Electrically conductive
yes Form surface
wavy Info 1
Temperature range depending on the medium passed through Length per roll (m)
40 Material ceiling
rubber Material core
UHMWPE Material pressure carrier
synthetic textile fabricsteel wire spiral
Name hose
winkler Chemie universal® Operating pressure (bar)
16 PU
by the meter Standard
DIN EN 12115 Suction capacity (bar)
0,9 Temperature range from (°C)
-40 Temperature range to (°C)
100 Usage details medium
AdBlue®aldehyde
aliphatic hydrocarbons
aromatic hydrocarbons
chlorinated hydrocarbon
Ester
ketone
alkali
acids
Usage medium
liquidschemicals
Version
pressure hosesuction hose
Wall thickness (mm)
8 Weight (kg)
3 ø external (mm)
91 ø internal (inches)
3 ø internal (mm)
76
