Brand
Prokosch Color gaiter
black Info 1
thread valve body M 10x8 Material flange
gray cast iron Material gaiter
NBR Material housing
aluminum Max. control pressure (bar)
5 Max. operating pressure (bar)
6 Nominal diameter (mm)
80 Number of mounting holes
8 Overall length (mm)
280 Recommended differential pressure (bar)
1,5-2 Standard flange
TW1 Standard flange DIN
28460 Thread internal air connection metric
M 14x1,5 Usage
tank and silo technology Weight (kg)
6 ø hole circle (mm)
130 ø mounting holes (mm)
11
